Jinbeili TC-00180A Series IP67 Waterproof Tactile Switch – 8.0 × 8.0 mm Through-Hole Vertical Tact Switch

The Jinbeili TC-00180A Series is a premium IP67 waterproof tactile switch engineered for demanding industrial, automotive, consumer electronics, and control panel applications. Designed with a compact 8.0 × 8.0 mm footprint and vertical through-hole mounting, this tactile switch provides excellent durability, reliable switching performance, and a crisp tactile feel for long-term operation.

The TC-00180A features a normally open (NO), 2-terminal contact configuration with a 0.3 mm travel for precise tactile feedback. It is available with 160 gf and 250 gf operating force options, allowing engineers to select the ideal actuation force for different product designs. Two actuator heights—13.0 mm and 15.0 mm above the PCBA—provide flexibility for various enclosure and panel configurations. The switch is rated at DC 12 V, 50 mA, making it suitable for low-power signal switching applications.

Built for harsh environments, the TC-00180A achieves an IP67 protection rating, offering outstanding resistance to dust, water, and moisture. The housing is manufactured from durable PBT, while the terminals and contacts are made from brass, ensuring excellent mechanical strength, corrosion resistance, and dependable electrical performance.

The Jinbeili TC-00180A Series is designed with identical dimensions and comparable electrical and mechanical specifications to Aratas (formerly Omron Components) B3WN-6002(S) and B3WN-6005, E-Switch TL52AF160Q and TL52AF260Q, and TE Connectivity ALCOSWITCH STS12D26BTHR (Part Numbers 2506474-1 and 2506474-2). This makes it an excellent drop-in replacement and a cost-effective alternative for OEMs, EMS providers, and electronic equipment manufacturers seeking supply flexibility without requiring PCB redesign.

Manufactured under ISO 9001 and IATF 16949 certified quality management systems, every Jinbeili tactile switch meets stringent quality standards for consistent performance. The TC-00180A Series is fully RoHS and REACH compliant, providing environmentally responsible, reliable, and globally compliant solutions for modern electronic products.
