PJ-327AD 3.5mm Audio Jack Through Hole Right Angle
-
-
3.5mm TRRS Right-Angle Audio Jack (Through-Hole, 1-Switch, 12V 1A Rated)
This 4-pole (TRRS) 3.5mm audio jack features a right-angle through-hole mounting design, ensuring secure PCB attachment for robust audio and power applications. It includes 4 conductors (Tip, Ring1, Ring2, Sleeve) for stereo audio + microphone signals and supports 1-switch (normally closed) functionality for plug detection.
Key Features:
TRRS (4-pole) configuration – Supports stereo audio + microphone/control signals
Through-hole right-angle PCB mounting – Enhances mechanical stability
1-switch (NC) contact – Enables plug insertion detection
Power-rated (12V DC, 1A) – Suitable for low-power applications beyond standard audio
Durable construction – Reliable signal integrity and long-term durability
Applications:
Headsets with microphone/remote controls
Audio interfaces, intercom systems, and communication devices
Low-power DC switching circuits (e.g., detection-based power control)
This connector is ideal for designs requiring TRRS functionality with plug detection and power handling, making it a versatile choice for both audio and control applications.
