MK-13D70E-L Momentary Slide Switch SP3T SMT Right Angle
-
-
This miniature slide switch features a Single Pole Triple Throw (SP3T) configuration with a right-angle SMT design. It includes a self-reset mechanism with a single internal spring that allows the actuator to return smoothly from the left side. Operating in an on-on-Mom function, this switch is rated for DC 30V and 0.1A, with compact dimensions of 12.65mm x 2mm, making it ideal for space-constrained applications. Its exceptional performance positions it as an excellent alternative to the Nidec Components Corporation CSS-1311B CSS-1311TB MCSSS-12RG
Previous:
SS-22H30 DPDT Slide Switch THT Hole
Next:
MK-13D70E-R Self Reset Slide Switch 1P3T SMT Right Angle
momentary slide switch on on mom self reset SP3T 1P3T Slide Switches SMD Right Angle SP3T Slide Switch
Write your message here and send it to us
This miniature slide switch features a Single Pole Triple Throw (SP3T) configuration with a right-angle SMT design. It includes a self-reset mechanism with a single internal spring that allows the actuator to return smoothly from the left side. Operating in an on-on-Mom function, this switch is rated for DC 30V and 0.1A, with compact dimensions of 12.65mm x 2mm, making it ideal for space-constrained applications. Its exceptional performance positions it as an excellent alternative to the Nidec Components Corporation CSS-1311B CSS-1311TB MCSSS-12RG
