TS-1505 10x10mm 5 Way Navigation Switch
-
-
The 4-Way Navigation Switch (also known as a 2-Axis Digital Joystick or Multidirectional Tact Switch) is a compact, surface-mount (SMD) control component designed for precise directional input in space-constrained electronics. Measuring a slim 10 × 10 mm footprint on the PCB, it features a total actuator height of 9.2 mm above the board surface, providing comfortable tactile travel and ergonomic operation.
This switch delivers reliable 4-directional (up, down, left, right) actuation through independent mechanical contacts, with a clear center-select function when pressed downward—ideal for menu navigation, scrolling, gaming controls, remote interfaces, wearables, and handheld devices. Rated for DC 12V / 0.1A, it handles low-power digital signals with excellent durability and crisp feedback.
As a high-quality alternative to the Adafruit Industries 5223 SMT 5-Way Navigation Switch, this model offers equivalent or improved compatibility in pinout, mounting, and functionality while maintaining a similar compact form factor. Its robust construction ensures long service life under repeated use, with low contact resistance and minimal bounce for clean microcontroller interfacing (e.g., Arduino, Raspberry Pi, or custom PCBs).
Perfect for designers seeking a cost-effective, drop-in replacement that combines miniature size, intuitive multidirectional control, and dependable performance in modern compact electronics.
