SS-23H02 Slide Switch DP3T THT Hole
-
-
This high-quality 2P3T (Double Pole, Triple Throw) slide switch is designed for reliable switching in electronic circuits and control panels. Featuring a shorting (make-before-break) contact configuration, it ensures smooth and continuous signal transfer during position changes, minimizing glitches and noise in sensitive applications.
The switch is built for vertical through-hole PCB mounting, offering stable and secure installation. With a compact outline dimension of 25.6 × 9.2 mm and a smooth 4.0 mm actuator travel, it provides precise tactile feedback and excellent operational feel. It is rated for DC 30V at 0.3A, making it suitable for low-power signal switching, audio equipment, instrumentation, and various consumer electronics.
For secure mechanical mounting, the switch includes two M2.6 screw holes, allowing easy and robust screw fixing in addition to PCB soldering. The actuator length is available in multiple options: 3mm, 4mm, 5mm, 6mm, and 7mm, giving designers flexibility to match different panel thicknesses and ergonomic requirements.
Durable construction and consistent performance make this 2P3T slide switch an ideal choice for industrial controls, test equipment, and DIY electronics projects where reliability and versatility are essential.
FAQS:
Q1, Can you make this slide switch with Non-shorting circuit ?
A1: Yes, we can customize it with non shorting type, but we need make a new mold of metal, and there would be tooling cost generated
Q2: Do you have DP3T Slide switch surface mount right angle ?
A2: So, we don’t have SMT type
Q3: Can you make this slide switch with 10mm actuator length?
A3 : Yes, however 10mm actuator has a possibility of being broken when push hard.
