PJ-242C 4 Poles TRRS Audio Jack 2.5mm Mid Mount SMD
-
-
The 2.5mm SMD right-angle Mid Mount Board Cutout offset 1.2mm, 4 Poles TRRS Jack is a specialized audio jack designed for use in phones and other compact electronic devices. It features a 2.5mm diameter plug hole, making it suitable for connecting headphones, microphones, or other audio accessories. The jack is surface-mountable (SMD), allowing for easy installation on circuit boards.
The right-angle design of the jack allows it to be mounted flush with the device’s surface, saving space and providing a sleek appearance. The Mid Mount Board Cutout offset of 1.2mm ensures that the jack sits properly on the circuit board, with the cutout providing clearance for the jack’s housing.
The 4 Poles TRRS configuration of the jack supports Tip, Ring, Ring, Sleeve (TRRS) connections, allowing for the transmission of stereo audio signals as well as a microphone signal and a ground connection. This makes it ideal for use in smartphones, tablets, and other devices that require a single jack for multiple audio functions.
